Detail
AXIS P1468-LE 02342-001 Bullet Camera
Fully featured, all-around 4K surveillance
Lightfinder 2.0, Forensic WDR, OptimizedIR
Analytics with deep learning
Audio and I/O connectivity
Built-in cybersecurity features
Impact and weather resistant
Part number for ordering
NAME AXIS REGION PART NUMBER
AXIS P1468-LE AR, AU, BR, CN, EU, JP, KR, UK, US
02342-001
AXIS P1468-LE IN
02342-113
Technical specifications
Models: AXIS P1468-LE
Camera
Property description Property value
Image sensor CMOS
Image sensor size 1/1.2
Lightfinder Lightfinder 2.0
Wide dynamic range Forensic WDR
Min illumination/ light sensitivity (Color) 0.07 lux
Min illumination/ light sensitivity (B/W) 0 lux
Video
Property description Property value
Max video resolution 3840x2160
Max frames per second 50/60
Electronic image stabilization –
Lens
Property description Property value
Focal length 6.2 - 12.9 mm
Optical zoom 2.08
Horizontal field of view 108 - 49 °
Vertical field of view 58 - 27 °
Compression
Property description Property value
Zipstream Yes
H.264 Baseline, High, Main
H.265 Yes
Motion JPEG Yes
Audio
Property description Property value
Audio Support Yes
Network
Property description Property value
PoE Class 3
Security
Property description Property value
Signed firmware Yes
Secure boot Yes
General
Property description Property value
Remote focus Yes
Remote zoom Yes
Built-in IR Yes
Local storage (memory card slot) Yes
Operating temperature -40 to 60 °C
Outdoor Ready Yes
Vandal rating IK10
IP rating IP66, IP67
Designed for repaint –
Sustainability BFR/CFR free, PVC free
Power
Property description Property value
Power (max) 13.0 W
Power (average) 7.6 W
