Specification / model

SPD-3750P

SPD-3710P

SPD-3320P

SPD-2710P

VIDEO

Camera element

1/4" Vertical double density CCD

1/4" Super HAD CCD

Total pixels

795 (horizontal) x 596 (vertical)

Effective pixel

752(horizontal) x 582 (vertical)

Scanning system

2:1 Interlaced scan

Synchronization mode

Internal / external synchronization

Scanning frequency

Horizontal：15.625KHz/vertical：50Hz

Horizontal resolution

Colour：550TV line，Black and white：680TV line

Minimum illumination

Colour：0.7Lux@F1.65 (50IRE),0.001Lux (Sens-up, 512x)
Black and white：0.03Lux@F1.65 (50IRE)

Colour：0.4Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
Black and white：0.02Lux@F1.65 (50IRE)

Signal to noise ratio

52dB

Video output

CVBS: 1.0Vp-p/75 ohm composite video

Camera lens

Variable focal length

3.5~129.5mm (37xOptical zoom)

3.5~115.5mm(33xOptical zoom）

3.5~94.5mm(27xOptical zoom）

Maximum aperture ratio

1:1.6(Wide)~3.9(Tele)

1:1.6(Wide)~3.6(Tele)

Lens viewing angle

H:55.5°(Wide)~1.59°(Tele) /
V:42.5°(Wide)~1.19°(Telel)

H:55.5°(Wide)~1.77°(Tele) /
V:42.5°(Wide)~1.33°(Telel)

H:55.5°(Wide)~2.24°(Tele) /
V:42.5°(Wide)~1.79°(Telel)

Lens type

Manual / automatic / primary focus

Minimum visible distance

1m

1.9m

Zoom speed

2.5 Seconds (wide angle to telephoto)

Pan / Tilt

Horizontal rotation range

360°

Horizontal rotation speed

Preset：500° /Seconds，Manual: 0.024 ° / S ~ 120 ° / S

Vertical rotation range

 -5°~185°

-6°~186°

Vertical rotation speed

Preset：500° /Seconds，Manual: 0.024 ° / S ~ 120 ° / S

Preset position

255

Preset bit accuracy

±0.1°

Function

Screen display

Support multiple languages: English, French, German, Spanish, Italian, Chinese, Russian, polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese

Camera identification number

Off / on (up to 12 bytes)

Day night conversion

ICR Day night conversion/Colour/Black and white

Backlight compensation

BLC/HLC/OFF

Wide dynamic

160x

Contrast enhancement

XDR ((off / low / medium / high))

Digital noise reduction

Adaptive 3D + 2D class (off / low / medium / high / user)

Digital image stabilization

On / off

Dynamic detection

Off / tracking / detection

Privacy masking

On / off (8 areas can be set)

Sensitivity

2x~512x

Automatic gain

Low / medium / high / manual / off

White balance

Automatic tracking / automatic white balance / manual / indoor / outdoor

Shutter speed

1/50 ~ 1/120,000sec

Digital zoom

Off / on (1x ~ 16x)

Digital Flip

 Flip horizontal / Flip Vertical

Intelligent analysis

 Fixed / Mobile

Picture in picture

 On / off

Timetable

 Date/time

Alarm

 4 channels input, 2 channels output, 1 additional interface

Remote control

 Coaxial visual control（coordination SPC-300P), RS-485

Protocol

 Coax : CCVC
 RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE

Environment

Operating temperature / humidity

 -10℃~+50℃/80%RH within

Power

Power Supply

 24V AC

Power rate

 Maximum 13W

Product specification

Color / material

 Ivory / plastic

Dimensions (W x H x D)

 ?155x243.4mm

weight

 2Kg
